Recoil Check Valves
The AVM Recoil Check Valve is a computer-optimised, streamlined design for low head-loss. It is designed for the water and sewage industry, taking into account the best available technology, exceeding the requirements of EN 1074.
Specifications:
Size Range: DN 80 - DN 2000
Working pressure: PN 10 - PN 40
Design standards: EN 1074
Medium: Water, Sewage
Features:
- Large, rugged design
- Full bore design and streamlined disc results in low head-loss
- Top cover for easy maintenance
- Slanted disc design results in shorter stroke, faster closure and less transients
- Expanded body allows resistance-free flow and compensates for the shorter stroke
- Light-weight disc gives less head-loss, and faster reaction to back-flow
- Weld-deposit bronze seats
- Flanged ends to EN 1092-2 PN 10 to PN 40 or ANSI B16.5 Class 125, 250 or 300
- Powder epoxy coating with drinking water certificate
- Option for limit switch
